Gehl CTL Series Poly Windshield

Price range: $493.00 through $776.00

Fits the following models:

Gehl CTL55, CTL60, CTL65, CTL70, CTL75, CTL80, CTL85

Replaces OEM Glass #:

#182122 (without holes) & #182084 (with holes)

Thickness

Tinted

Wiper Selection

Clear

Model *

Product Description

🛠️ Gehl CTL Series Polycarbonate Windshield

Replace your factory Gehl front windshield with a tougher, lighter polycarbonate version engineered for performance. This panel mirrors the OEM fit, giving you the same mounting points and install ease — but upgraded strength, clarity, and comfort.

LEAD TIME: 10-25 BUSINESS DAYS

OEM mounting match: Replaces glass using the same mounting holes, so it works with your existing hardware.
High strength material: Clear Lexan / polycarbonate — ~250× stronger than glass and about half the weight.
Durable & safe: Coated to resist abrasion, reducing scratches and wear over time.
Noise & thermal control: Helps lower cabin noise and moderates heat gain (summer) / heat loss (winter).
Improved visibility: Maximizes light transmission while maintaining protection.
Milled edges: Precision milled edges make seal transfer or replacement easier and more accurate.
Hardware not included: Uses your existing bolts, frame, seals, and door parts.

Compatibility

📋 Fits the following Gehl CTL Series models:

CTL55, CTL60, CTL65, CTL70, CTL75, CTL80, CTL85

Replaces OEM glass part #182122 (without holes) & #182084 (with holes).
Available in 1/4″ & 1/2″ thick polycarbonate.

Features

OEM Replacement

Direct replacement for factory glass — uses the same mounting holes and your current hardware.

Clear or 50% Tinted

Choose a clear panel for maximum light, or a 50% tinted version to reduce glare and heat gain.

Superior Strength

Constructed from Lexan/polycarbonate, offering vastly superior impact resistance and reduced weight.

Durable & Safe

Abrasion-resistant coating protects against scratches and wear, helping maintain long term visibility.

Easy Installation

Milled edges provide precise sealing without extra trimming. And since it uses your existing hardware, installation is fast and straightforward.

Enhanced Cabin Performance

Better visibility, less noise, and improved insulation from heat/cold — a practical upgrade for daily use.

Warranty

LIMITED WARRANTY

If the windshield/window (i) breaks, (ii) incurs coating failure, (iii) exhibits excessive increased haze, or (iv) exhibits excessive yellowing or loss of light transmission—each within ten (10) years from the date of sale due to manufacturing defect and subject to the definitions and conditions set forth herein—the purchaser will receive a free replacement windshield/window, provided the failed windshield/window, original sales receipt, and this warranty are returned to the original dealer. If a replacement windshield/window cannot be provided within fourteen (14) days, the manufacturer may opt to refund the original windshield/window purchase price.

CONDITIONS

This warranty applies only when the windshield/window is used in flat vertical architectural glazing, excluding transportation, outdoor recreational, and off-road vehicle applications. The product must be cleaned according to recommended guidelines (see reverse side for cleaning instructions). This warranty does not cover (re)installation expenses or any other direct or indirect loss(es) resulting from windshield/window failure.

Breakage: The warranty against breakage applies only to a windshield/window fabricated, installed, and cleaned according to recommendations. The windshield/window is substantially stronger than acrylic and resists impact, abuse, and vandalism. However, no material can be described as unbreakable, as all use cases cannot be accounted for.

Coating Failure: The warranty covers coating failure when the abrasion-resistant surface treatment visibly flakes or loses adhesion to the substrate sheet, detectable without instruments.

Abrasion Resistance: The windshield/window will not exhibit an increase in haze of more than 15%.
Test Criteria: The sample as manufactured shall be abraded per ANSI Z26.1 (Taber Abrader, Test No. 17) for 100 cycles with a 500g load.

Yellowing and Light Transmission: This applies only to clear, transparent windshield/windows.

The Yellowness Index (YI) shall be less than 5.0 within five years and less than 10 within ten years from sale date, per ASTM D1925 (1977), as measured with a Gardner Colorimeter.
Light transmission loss shall not exceed 5% within five years and 7% within ten years, per ASTM D1003 testing protocols.
This warranty does not cover yellowing or light transmission losses due to dirt, atmospheric deposits, abrasion, or physical changes unrelated to material degradation. Regular cleaning reduces, but does not prevent, this effect.

This warranty does not apply to hazing caused by physical abuse or improper cleaning methods.

LIMITATION OF LIABILITY

The warranties stated herein are the only warranties provided and are in lieu of all other warranties—written or oral, statutory, expressed or implied—including any warranty of merchantability or fitness for a particular purpose.

The manufacturer shall not be liable for special, consequential, or incidental damages arising from use or application of the windshield/window, whether the claim is based on warranty, contract, tort, or other legal theory. Liability shall not exceed the original purchase price of the product.

The remedies described are the purchaser’s sole and exclusive remedies.
